Description:
Titan Flow Control CV80SV0050 Features:
- Wafer Type.
- 1/2 Inch Check Valve.
- Body: Stainless Steel A351 Gr. CF8M.
- Disc Material: Stainless Steel.
- Disc Seat: Viton.
Additional Features
Quick Closure to Reduce Water Hammer:
Silent shut-off is achieved via the fully automatic, spring assisted disc that closes near zero flow velocity, the lightweight, center guided disc design creates a positive shutoff prior to flow reversal and helps to keep slamming and surges to a minimum.
Minimal Head Loss:
The contour of body provides a short and straight flow path that generates very little turbulence. Additionally, the spring-loaded, center guided disc is designed with very low cracking pressure which reduces the amount of energy required to open the valve.
Bubble Tight Seal:
By utilizing an optional viton seat and PTFE gasket in conjunction with precision machined sealing surfaces, the CV80SS maintains a bubble tight seal that meets or exceeds AP1598 leakage requirements.
Designed for Long Life:
The CV80SS utilizes a highly reliable investment casting, stainless steel construction, and a simplified design, only 6 parts that can provide a long service life for a wide variety of applications.
