Century Motors DSB1016 Direct Drive Blower Motor, 1/6HP, 115V, 1075 RPM, Single Phase

(No reviews yet) Write a Review

$298.32

4 In Stock, Orders Placed By 3pm EST Ship Same Day (Weekends And Holidays Excluded)

Free ground shipping to the lower 48 states

Product ID:
V01-Century-Motors-DSB1016
Weight:
13.00 (Lbs.)
Ships By:
Free Ground, Or Choose Expedited Shipping At Checkout
Ships From:
Illinois - Direct From Supplier
Adding to cart… The item has been added

Century Motors DSB1016 Direct Drive Blower Motor Features:
- 1/6Hp.
- 115V.
- 1075Rpm.
- Single Phase.
- 3 Speed.
- 3.1 Amps.
- 48Y Nema Frame Size.
- Semi Enclosed.
- Sleeve Bearing.
- 7 1/2" x 1/2" 7 1/2" Shaft.
- CCW Lead End Rotation.

Additional Features:
The Century Motors DSB1016 is a permanent split capacitor (PSC) direct drive blower motor designed for HVAC applications. It provides 1/6 HP, operates at 1075 RPM with 3 speeds, runs on 115V single-phase 60 Hz power drawing 3.1 amps, and features a 48Y frame (5-5/8 inch diameter), double shaft, open air over (OAO) or semi-enclosed enclosure, automatic thermal protection, resilient mounting, and continuous air-over duty.
