Johnson Controls M9208-BAA-3 Electric Actuator, Spring Return, 2 Position, 120 VAC, 60 HZ

(No reviews yet) Write a Review

$287.27

2 In Stock, Orders Placed By 3pm EST Ship Same Day (Weekends And Holidays Excluded)

Free ground shipping to the lower 48 states

Product ID:
V01-Johnson-Controls-M9208-BAA-3
Weight:
6.00 (Lbs.)
Ships By:
Free Ground, Or Choose Expedited Shipping At Checkout
Ships From:
Illinois - Direct From Supplier
Adding to cart… The item has been added

Johnson Controls M9208-BAA-3 Electric Actuator Features:
- 120 VAC.
- 60 HZ.
- On/Off.
- 2 Position.
- 70 LB-In Torque.
- 55-71 Second Power On Run Time.
- 48 Inch Appliance Cable.
- With Integral 3/8 Inch FMC Connector.
- Spring Return.
- Direct Coupled.

Additional Features:

The Johnson Controls M9208-BAA-3 is a 120 VAC on/off electric spring-return actuator that delivers 70 LB-In of torque with a 55–71 second powered rotation and 13–26 second spring return for reliable fail-safe operation. Designed for direct mounting on HVAC dampers, it features a 90 degree adjustable rotation, NEMA 2/IP54 enclosure, manual override, and electronic stall detection.
