Continental Fan AXS150-EC In-Line Duct Fan, 6 Inch, 306 CFM, 120V/1Ph
Continental Fan
$363.20
Usually Ships In 3-5 Business Days
Free ground shipping to the lower 48 states
- Product ID:
- Continental-Fan-AXS150-EC
- UPC:
- 627249122104
- Weight:
- 9.00 (Lbs.)
- Ships By:
- Free Ground
- Ships From:
- New York - Direct From Continental Fan
Description:
Continental Fan AXS150-EC In-Line Duct Fan Features:
- 6 Inch.
- 306 CFM.
- 120V/1Ph.
- Efficient electronically commutated (EC) motorized impeller.
- Energy efficient.
- Corrosion resistant, durable steel housing with a polymer coating.
- 120V, 60 Hz operation; single phase.
- Easy to install – mounting brackets included.
- Suitable for air temperatures up to 105 F.
- Optional pre-wired with 120V power cord (See -C models).
- Speed controllable 0-10 V.
- External rotor motor design results in superior motor cooling and durability.
- Rated for continuous operation.
- Permanently lubricated ball bearing motor for maintenance-free operation.
- Automatic reset thermal overload protection.
- Fan and motor are precision balanced for quiet and vibration-free operation.
- Energy efficient.
- Corrosion resistant, durable steel housing with a polymer coating.
- 120V, 60 Hz operation; single phase.
- Easy to install – mounting brackets included.
- Suitable for air temperatures up to 105 F.
- Optional pre-wired with 120V power cord (See -C models).
- Speed controllable 0-10 V.
- External rotor motor design results in superior motor cooling and durability.
- Rated for continuous operation.
- Permanently lubricated ball bearing motor for maintenance-free operation.
- Automatic reset thermal overload protection.
- Fan and motor are precision balanced for quiet and vibration-free operation.
Additional Features
AXS EC In-Line Duct Fans are designed for residential, commercial and light industrial ventilation applications. The highly efficient backward-curved impeller can develop significant pressure. Moreover, the in-line configuration simplifies installation.
With its efficient electronically commutated (EC) motorized impeller, AXS EC in-line duct fans set new standards for efficiency and versatility. AXS EC fans incorporate a corrosion resistant steel housing with a polymer coating. They are available in sizes from 4” to 12”, with airflows ranging from 151 cfm to 801 cfm.
