Titan Flow Control TF21I0600 6 Inch Check Valve, Flanged Ends Type, Cast Iron Body, EPDM Seat

(No reviews yet) Write a Review
$1,907.58

Usually Ships In 1-2 Weeks

Free ground shipping to the lower 48 states

Product ID:
Titan-Flow-Control-TF21I0600
Weight:
202.00 (Lbs.)
Ships By:
Truck, Curbside, Back Of Truck
Ships From:
North Carolina - Direct From Titan

choose options:

Frequently Bought Together

Please choose options for all selected products

  • Choose Options

Description:

Titan Flow Control TF21I0500 Features:
- Flanged Ends.
- 6 Inch Check Valve.
- Body: Cast Iron A126B.
- Disc Material: Ductile Iron A536.
- Disc Seat: EPDM.

Additional Features:

Economical and Convenient Design:
Titan’s Tri-flow Control Check Valve is three valves in one, replacing a calibrated balance valve, shut-off valve, and silent check valve for a simplified and inexpensive way to control flow from a pump. Flow through the valve is adjustable from zero to full by the ACME rising stem. A graduated position indicator on the stem provides an accurate check of the valve’s position for throttling service, and a hand-wheel is provided with all Tri-flow control check valves for ease of operation. The Tri-Flow also has a soft-seated, dovetail O-ring groove ensuring a bubble tight seal in the closed position.

Quick Closure to Reduce Water Hammer:
Silent shut-off is achieved via the fully automatic, spring assisted disc that closes near zero flow velocity when functioning as a check valve. The soft seat and quick closure helps to prevent flow reversal, slamming, and surges.

Minimal Head Loss:
The valve’s body has a large body with at least a 2 to 1 ratio to connecting pipe. The disc's low cracking pressure reduces the amount of energy required to open the valve.
