Titan Flow Control TF21I0400 Features:
- Flanged Ends.
- 4 Inch Check Valve.
- Body: Cast Iron A126B.
- Disc Material: Ductile Iron A536.
- Disc Seat: EPDM.
Economical and Convenient Design:
Titan’s Tri-flow Control Check Valve is three valves in one, replacing a calibrated balance valve, shut-off valve, and silent check valve for a simplified and inexpensive way to control flow from a pump. Flow through the valve is adjustable from zero to full by the ACME rising stem. A graduated position indicator on the stem provides an accurate check of the valve’s position for throttling service, and a hand-wheel is provided with all Tri-flow control check valves for ease of operation. The Tri-Flow also has a soft-seated, dovetail O-ring groove ensuring a bubble tight seal in the closed position.
Quick Closure to Reduce Water Hammer:
Silent shut-off is achieved via the fully automatic, spring assisted disc that closes near zero flow velocity when functioning as a check valve. The soft seat and quick closure helps to prevent flow reversal, slamming, and surges.
Minimal Head Loss:
The valve’s body has a large body with at least a 2 to 1 ratio to connecting pipe. The disc's low cracking pressure reduces the amount of energy required to open the valve.
