Johnson Controls M9208-BAC-3 Electric Actuator, Spring Return, 2 Position, 120 VAC, 60 HZ, 2 SPDT

(No reviews yet) Write a Review

$328.96

2 In Stock, Orders Placed By 3pm EST Ship Same Day (Weekends And Holidays Excluded)

Free ground shipping to the lower 48 states

Product ID:
V01-Johnson-Controls-M9208-BAC-3
Weight:
6.00 (Lbs.)
Ships By:
Free Ground, Or Choose Expedited Shipping At Checkout
Ships From:
Illinois - Direct From Supplier
Adding to cart… The item has been added

Johnson Controls M9208-BAC-3 Electric Actuator Features:
- 120 VAC.
- 60 HZ.
- On/Off.
- 2 Position.
- 70 LB-In Torque.
- 55-71 Second Power On Run Time.
- 48 Inch Appliance Cable.
- With Integral 3/8 Inch FMC Connector.
- Spring Return.
- Direct Coupled.

- 2 SPDT Auxiliary Switches.

Additional Features:

The M9208-BAC-3 is a 120 VAC, 70 LB-In spring-return electric damper actuator designed for two-position On/Off control of HVAC dampers. It features direct-coupled mounting, 95 degree rotation, two SPDT auxiliary switches, electronic stall detection, a locking manual override, and a NEMA 2/IP54 enclosure, making it suitable for reliable fail-safe control of outdoor air, return air, and exhaust air dampers in commercial building automation systems.
