Honeywell VGF22ES30 Flanged Globe Valve 2-Way Equal percent 3" Cv116

Honeywell VGF22ES30 Flanged Globe Valve 2-Way Equal percent 3" Cv116

(No reviews yet) Write a Review
$1,896.88

Usually Ships In 1-2 Weeks

Free ground shipping to the lower 48 states

Questions? Contact us
Product ID:
VGF22ES30
Weight:
87.00 (Lbs.)
Ships From:
Illinois
Ships By:
Truck, Curbside, Back Of Truck

Links To Product Literature:

Honeywell VGF Flanged Globe Valves Installation Manual
Honeywell VGF Flanged Globe Valves Technical Data

Temporarily Out of Stock. More on Order. Click REQUEST A QUOTE for Current Lead Time and to PLACE AN ORDER.

Frequently Bought Together

Please choose options for all selected products

Description:

Honeywell VGF22ES30 Flanged Globe Valve 2-Way Equal Percentage 3" Cv116 VGF Flanged Globe Valves are used for 2-position or modulating control of steam, hot water, or chilled water-glycol solutions up to 50 percent concentration, in closed loop heating, ventilation and air conditioning (HVAC) systems. Features: ANSI Class 125 cast iron bodies with flanged end connections. Equal percentage and linear flow characteristics. Face-to-face flange dimensions per ANSI/ISA S75.03 standard Sizes from 2-1/2 to 6 in. Stainless steel trim standard for long life span. Differential pressure of 175 psi, ANSI Class IV leakage. Steam inlet pressure up to 125 psig and 353 F maximum temperature. Self-adjusting packing. Accurate positioning with equal percentage and linear flow characteristics to ensure precise temperature control. Universal bonnet for direct-coupled electric and pneumatic actuators for easy mounting, or linkage coupled Modutrol™ Motors and MN/MS Series direct coupled actuators. Not suitable for combustible gasses.
