Honeywell MS7503A2130 Direct Coupled Damper Actuator, Spring Return, 24V, 4-20 mA, 500 Ohm For Zelix S03 Series

(No reviews yet) Write a Review

$458.09

4 In Stock, Orders Placed By 3pm EST Ship Same Day (Weekends And Holidays Excluded)

Free ground shipping to the lower 48 states

Product ID:
V01-Honeywell-MS7503A2130
Weight:
3.00 (Lbs.)
Ships By:
Free Ground, Or Choose Expedited Shipping At Checkout
Ships From:
Illinois - Direct From Supplier
Adding to cart… The item has been added

Honeywell MS7503A2130 Damper Actuator Features:
- Direct Coupled.
- Spring Return.
- 24V.
- 4-20 mA.
- 27 LB-In Torque.
- 0/2-10 VDC.
- 500 Ohm Resistor.
- On/Off.
- SPDT Floating Control Signal,.
- 2-10 VDC Feedback.
- 1 Internal Auxiliary Switch
- 90 Second Nominal Driving Time.
- 25 Second Maximum Spring Return.
- Includes Mounting Bracket And Self Centering Shaft Adapter.
- 5-95 Percentage RH Humidity Range.
- 95±3 Degrees Rotation Stroke.
- -40-149 Degree Ambient Temperature.
- For Zelix S03 Series.

Additional Features:
The Honeywell MS7503A2130 is a 24 Vac/Vdc, 27 lb-in spring-return direct-coupled actuator designed for HVAC dampers and quarter-turn valves. It floating SPDT, on/off, and 02-10 Vdc modulating control with 02-10 Vdc feedback, includes one internal SPDT auxiliary switch, provides a 95 degree rotation with a 90-second drive time, and features a NEMA 2/IP54 plenum-rated enclosure for reliable commercial HVAC applications.
